Warranty
25 year vessel warranty available on vessel only & 2 year warranty available on components. Subject to terms & conditions.
Features and Benefits
- 2 year parts warranty
- 25 year vessel warranty
- Low standing heat loss
- Lightweight for easy installation
- Wider base for additional stability
- Duplex stainless steel construction
- Manufactured in accordance with BS EN 12897
- Complete with all quality fittings according to model
- Rubber connection labels with retention foam
- New flat top & base with 20% more HCFC insulation
-
Duplex Stainless Steel
-
Rubber Connection Labels
-
Wider Base for Additional Stability
-
New Flat Top & Base
-
Lightweight for easy installaiton
-
Low Standing Heat Loss
-
Tapping Positions to BS1566 Specifications
Technical Specification
| Cylinder model | 180 | 210 | 250 | 300 | 400 |
|---|---|---|---|---|---|
| Size | |||||
| Height (mm) | 1306 | 1494 | 1744 | 1990 | 2030 |
| Diameter (mm) | 550 | 550 | 550 | 550 | 550 |
| Weight (empty) (kg) | 31 | 35 | 40 | 44 | 59 |
| Weight (full) (kg) | 209 | 243 | 288 | 331 | 459 |
| Capacity (litres) | 178 | 208 | 248 | 287 | 393 |
| Performance | |||||
| Pressure regulator (bar) | 3 | 3 | 3 | 3 | 3 |
| Expansion vessel size (litres) | 18 | 24 | 24 | 35 | 2 x 24 |
| Rating of primary coil (kW) | 18.0 | 18.5 | 19 | 20.5 | 22 |
| Heat up time from 15C to 60C (min) | 28 | 35 | 38 | 41 | 45 |
| Efficiency Class | B | B | C | C | C |
| Heat loss (watts) | 55 | 62 | 74 | 86 | 87 |
