Features & Benefits

  • 10 year warranty*
  • Backlit 3.5” LCD full colour display
  • Built using premium components
  • Up to 5:1 modulation
  • LPG conversion kit on all models
  • Low lift weight (starting from 30.7kg)
  • Multi-function buttons for simplified end user operation
  • Easy to read pressure gauge

Warranty

10 year warranty when registered within 30 days of installation and serviced annually. Subject to terms and conditions.

  • Icon Made For Ireland MADE FOR IRELAND
  • 10 Year Warranty 10 YEAR WARRANTY
  • Badge Simple Install SIMPLE TO INSTALL & SERVICE
  • Badge Lcd Colour Display LCD COLOUR DISPLAY
  • Badge Low Weight LOW LIFT WEIGHT
  • Badge Frost Protection FROST PROTECTION
  • Badge Flue Variants FLUE VARIANTS
  • Badge Nox Class 6 NOX CLASS 6

Technical Specification

The Vogue System IE boiler is available in the following outputs: 15kW, 18kW, 26kW, 32kW. With the latest advanced boiler diagnostics, system preferences and set up can be quickly and easily completed.

SYSTEM S15 SYSTEM S18 SYSTEM S26 SYSTEM S32
Size
Height (mm) 740 740 740 740
Width (mm) 445 445 445 445
Depth (mm) 330 330 330 330
Weight (packaged) kg 35.5 36.3 37.7 39.7
Max installation weight kg 30.7 31.5 32.9 34.3
Performance
CH output (kW) min/max @ 70°C 3.0 - 15.0 3.6 - 18.0 5.2 - 26.0 6.4 - 32.0
CH output (kW) min/max @ 40°C 3.2 - 16.2 3.9 - 19.3 5.6 - 27.9 6.8 - 34.3
DHW output (kW) max n/a n/a n/a n/a
DHW flow rating I/min. 35°C rise n/a n/a n/a n/a
SEAI HARP (2005) % 91 91.1 91.1 91.1
NOx classification CLASS 6 CLASS 6 CLASS 6 CLASS 6
Convertible to LPG Yes Yes Yes Yes
Flues
Max horizontal flue 10m 10m 10m 8m
Max vertical flue 10m 10m 10m 10m
ErP Efficiencies
Condensing boiler Yes Yes Yes Yes
Seasonal space heating efficiency class A A A A
Related heat output Kw 15 18 26 32
Seasonal space heating efficiency ŋs % 92.4 93.2 93.1 93.2
Sound power level, indoors Lwa dB 50 52 52 50
Water heating energy efficiency class n/a n/a n/a n/a

Controls & accessories

  • Mechanical Controls Preview

    Mechanical Timer

    Our 24 hour mechanical timer is a simple plug-in option. Continuous, timed or off modes can be set, providing 15 minute period operation.

    View product
