Warranty
2 year warranty, subject to terms & conditions.
Features & Benefits
- Smart control functions learning and adapting the energy consumption to the user's lifestyle
- Window open/closed detection function switching to minimum heating function as soon as a window opens
- Digital display unit and electronic thermostat
- Consumption indicator for responsible, informed use of the equipment
- Up to 45% energy savings thanks to integrated programming and presence detector
- Extensive heat panel with sensors, black painted extruded aluminium heating element & digital display
- 6 command pilot wire: Comfort, Comfort -1°C, Comfort -2°C, Eco, Frost-free, Off
- Easy to install: H shaped vertical support
- ASP (Anti-Staining Process) to reduce staining on wall and on eqipment
- Standard and high versions to adapt to the customers rooms
-
2 Year Warranty
-
Click & Go Heating
-
CozyTouch Compatible
-
Open Window Detection - Radiators
Technical Specification
| Output (w) | Depth (mm) | Width (mm) | Height (mm) | Weight (kg) | Model |
|---|---|---|---|---|---|
| 500 | 120 | 465 | 470 | 4.3 | AH566205 |
| 750 | 120 | 540 | 470 | 4.9 | AH566207 |
| 1000 | 120 | 615 | 470 | 5.5 | AH566210 |
| 1250 | 120 | 765 | 470 | 6.2 | AH566212 |
| 1500 | 120 | 1060 | 470 | 10 | AH566215 |
| 2000 | 120 | 1060 | 470 | 10 | AH566220 |
Controls & accessories
How to buy
Only fully trained and approved professional installers can fit Ideal boilers, so step 1 in your purchase is to choose your local Ideal installer.
